GF25 Rebar bending machine
A rebar bending machine is an automated device used for the efficient and precise production of rebar stirrups. It can quickly bend coiled or straight rebars into closed stirrups of various square, rectangular and other shapes, greatly improving production efficiency and consistency. It is widely used in construction fields such as buildings, bridges, and precast components.
GF25 Rebar bending machine Description
- Preparation
- Ensure the bending machine is on a stable working platform, free from obstructions.
- Check that the power cord is securely connected and the power socket is properly grounded.
- Check that the cutting tools and clamps on the bending machine are correctly installed and undamaged or loose.
- Power On
- Press the power switch to ensure the bending machine is powered on.
- Check the indicator lights on the control panel to ensure a normal power supply.
- Parameter Adjustment
- Set parameters such as bending angle and radius as needed.
- Adjust the bending speed and bending force according to the size and quantity of the reinforcing bars.
- Reinforcing Bar Installation
- Place the reinforcing bars to be bent onto the clamps of the bending machine.
- Ensure the reinforcing bars are correctly positioned and not misaligned or loose.
- Begin Bending
- Press the start button; the bending machine will begin operation.
- Observe the bending process, ensuring the reinforcing bars are bent to the predetermined angle and shape.
- During bending, carefully observe the bending machine’s operating status; if any abnormalities are detected, stop the machine immediately for inspection. 6. Completing the Bending
- Stop the bending machine when the rebar is bent to the predetermined angle and shape.
- Remove the bent rebar from the clamp and place it in the designated location.
- Turning Off the Power
- Press the power switch to turn off the power to the bending machine.
- Disconnect the power cord to ensure equipment safety.
| Model | GF20 | GF25 | GF28 | GF32 |
| Bending range | φ4-20mm | φ4-25mm | φ4-28mm | φ4-32mm |
| Bending angle | 90°/135° | 90°/135° | 90°/135° | 90°/135° |
| Motor power | 3KW | 3KW | 3KW | 3KW |
| Operating speed | 25-30r/min | 25-30r/min | 25-30r/min | 25-30r/min |
| Packing size（mm） | 860*56*830mm | 860*56*830mm | 850*600*840mm | 850*750*890mm |
| Weight | 95kg | 135kg | 190kg | 260kg |
