Intelligent, efficient, and energy-saving integrated design, combining straightening, bending, cutting, and other functions.
-
High efficiency: for 230*230 stirrups, about 1800 double-line pieces per minute; daily output of 9 tons per shift; small error with rebar length error of ±1mm and bending accuracy of ±1°.
-
High power: single-line processing of φ12 coil rebar, double-line processing of φ4–10 coil rebar.
-
Powerful intelligent functions: automatic protection, real-time monitoring of voltage and current, with remote control and positioning.
-
All electrical components adopt well-known domestic brands.
-
Hundreds of circular shapes can be pre-input, retrievable during processing, saving time and labor; shapes can also be edited freely according to drawing requirements.
-
Key components are made of special steel, ensuring long service life, low operating cost, and a guaranteed processing capacity of over 1000 tons of steel.
-
High quality and affordable price, excellent cost performance.
-
Full servo drive and PLC control, overcoming the shortcomings of traditional machines such as low efficiency and large errors.
-
Independent intellectual property rights, with a total of 12 national patents.
-
Visual LCD screen allows full control and monitoring from the start of equipment operation; networked data collection enables real-time monitoring of each machine’s daily output and working hours, as well as inventory levels and processed steel quantities.
Operating Procedure
-
Turn on the power supply of the control console.
-
Turn on the power supply of the main machine.
-
Switch on the power and check whether the sequence of the main machine cables is correct.
-
On the screen, click to press the large wheel (the small wheel will automatically release), then insert the rebar. Click to release the large wheel (the small wheel will automatically press).
-
On the screen, click the small wheel feeding button to feed the rebar under the large wheel. Then press the large wheel again, and click the large wheel feeding button to feed the rebar to the cutter position.
-
Rotate the knob to adjust the return parameters, then click start.
-
Test a single rebar for normal operation: choose any built-in shape, select the single option, set to automatic operation, then click the start button to check if the machine produces stirrups correctly.
-
Once the single stirrup straightening test runs normally, rotate to set continuous operation to begin normal production.
-
Enter the required rebar shape, length, and quantity on the screen, then click start to operate normally.
